The PEDROLLO 2CP pump range are twin impeller centrifugal pumps with close coupled motors. They are suitable for higher pressure domestic and industrial applications and are specially designed for continuos heavy duty use. A special feature of the design is a 'back-to-back' impeller configuration which balances radial loads and prolongs motor bearing life.
The pump body is constructed from cast iron and the impellers from brass alloy.
MOTOR
The close coupled fan cooled TEFC three-phase induction motors are non overloading and designed for continuous duty. A remote starter with thermal overload is necessary for motor protection.
Enclosure Class: IP44
Insulation Class: F
Voltage: 3x415V
Speed: 2900rpm
OPERATING CONDITIONS
Pumped liquid: Thin, clean, chemically non-aggressive liquids without abbrasive particles or fibres .
Max. Fluid Temperature: +90°C
Max. Ambient Temperature: +40°C
Max. Suction Lift: 7m (at sea level)
| Model |
Power
(kW) |
Current
(A) |
Dimensions (mm) |
Weight(kg) |
| DN1 |
DN2 |
L |
H |
W |
| 2CP 32/200C |
3 |
7.1 |
1½” |
1¼” |
464 |
304 |
266 |
39 |
| 2CP 32/200B |
4 |
10.2 |
|
|
|
|
|
43 |
| 2CP 32/210B |
5.5 |
11.5 |
2" |
|
541 |
334 |
292 |
54 |
| 2CP 32/210A |
7.5 |
15 |
|
|
|
|
|
60 |
| 2CP 40/180C |
4 |
9.8 |
|
1½” |
496 |
|
|
49 |
| 2CP 40/180A |
77.5 |
15.4 |
|
|
542 |
|
|
59 |
